ERW Pipes & Tubes

Bhansali Overseas offer a wide range of Electric Resistance Welded Pipes & Tubes, which has several exceptional attributes such as graded material, trustworthy, safe usage, well tested, hard-wearing, low maintenance, etc. Because of its consistency, perfect finish and durability corrosion resistance, these offered stainless steel ERW tubes are very much praised.

Stainless Steel Electric Resistance Welding Pipes, SS ERW Tubing, Electric Resistance Welding Pipes & Tubes Stockist, Carbon Steel ERW Pipe Suppliers.

Copper Nickel ERW Tubing, Super Duplex Steel ERW Tubing, Alloy Steel Electric Resistance Welding Pipes, Duplex Steel ERW Pipes Manufacturer, Inconel Electric Resistance Welding Tubing Dealer in India.

These ERW Tubes are recognized for its accuracy, durability, sturdy construction and precision designing. The efforts used in the manufacturing of these products are acquired from expert suppliers of the market after severely inspecting their durability and quality. We supply and procure extensive range of these ERW Pipes that are mass-produced from qualitative raw material by our reliable specialists. We also offer these Products in customized form with respect to its sizes and shapes to our clients.

ERW Pipes & Tubes

Electric Resistance Welding Pipes and Tubes Distributor

Electric Resistance Welding Pipes Specifications

ERW Pipes Pressure Rating

Electric Resistance Welding Tubing Material and Grades

ERW Pipes and Tubing Main Markets

ERW Pipes and Tubes Application

Send Enquiry

Most Widely Used Austenitic Electric Resistance Welding Pipes & Tubes, Stainless Steel ERW Tubing Exporter, ERW Pipes, ERW Tubes, SS Electric Resistance Welding Pipes, Titanium ERW Tubes, Hastelloy ERW Tubing, Electric Resistance Welding Pipes & Tubing Distributors in India.

ERW Pipes & Tubing Specification

Specification : ASTM, ASME, DIN, NFA, JIS

Thickness: 4.0mm - 100mm

Pipe Size : 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes

Tube Size : 1/2" OD to 8" OD

Length :Cut length, Fix length, Single Random, Double Random & Required Length

Form :Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes

End : Plain End, Beveled End, Treaded

Type : ERW Pipes & ERW Tubes

ERW Pipes Pressure Rating

Nominal Size- NPS (inches)	SCH	OD (inches)	Wall Thickness (inches)	ID (inches)	Bursting Internal Pressure (psi)	Collapsing External Pressure (psi)
1/8	10	0.405	0.049	0.307	18150	7468
	40	0.405	0.068	0.269	25195	10761
	80	0.405	0.095	0.215	35185	15441
1/4	10	0.540	0.065	0.410	18055	7425
	40	0.540	0.088	0.364	24444	10415
	80	0.540	0.119	0.302	33055	14445
3/8	10	0.678	0.065	0.545	14380	5705
	40	0.678	0.091	0.493	20132	8397
	80	0.678	0.126	0.423	27876	12021
1/2	5	0.840	0.065	0.710	11607	4407
	10	0.840	0.083	0.674	14821	5911
	40	0.840	0.109	0.622	19464	8084
	80	0.840	0.147	0.546	26250	11260
3/4	5	1.050	0.065	0.920	9285	3295
	10	1.050	0.083	0.884	11857	4524
	40	1.050	0.113	0.824	16142	6529
	80	1.050	0.154	0.742	22000	9271
1	5	1.315	0.065	1.185	7414	2445
	10	1.315	0.109	1.097	12433	3795
	40	1.315	0.133	1.049	15171	6075
	80	1.315	0.179	0.957	20418	8530
1 1/4	5	1.660	0.065	1.530	5873	1725
	10	1.660	0.109	1.442	9849	3585
	40	1.660	0.140	1.380	12650	3895
	80	1.660	0.191	1.278	17259	7052
1 1/2	5	1.900	0.065	1.770	5131	1376
	10	1.900	0.109	1.682	8605	3002
	40	1.900	0.145	1.610	11447	4332
	80	1.900	0.200	1.500	15789	6364
2	5	2.375	0.065	2.245	4105	896
	10	2.375	0.109	2.157	6884	2196
	40	2.375	0.154	2.067	9726	3526
	80	2.375	0.218	1.939	13768	5418
2 1/2	5	2.875	0.083	2.709	4330	1001
	10	2.875	0.120	2.635	6260	1905
	40	2.875	0.203	2.469	10591	3931
3	5	3.500	0.083	3.334	3557	639
	10	3.500	0.120	3.260	5142	1375
	40	3.500	0.216	3.068	9257	3307
3 1/2	5	4.000	0.083	3.834	3112	431
3 1/2	10	4.000	0.120	3.760	4500	1081
4	5	4.500	0.083	4.334	2766	315
	10	4.500	0.120	4.260	4000	845
	40	4.500	0.237	4.026	7900	2672
5	5	5.563	0.109	5.345	2949	350
5	10	5.563	0.134	5.295	3613	665
6	5	6.625	0.109	6.407	2467	129
6	10	6.625	0.134	6.357	3033	394

Electric Resistance Welding Pipes & Tubing Material & Grades:

Stainless Steel ERW Pipes & Tubes : ASTM A312, A790 TP-304/L/LN/H/N, TP-316/L/LN/H/N/Ti, TP-317L, TP-317LM, TP-321/H, TP-347/H. ASTM A213 / A269 / A270 / A632 TP series - 201, 202, 304, 304H, 304L, 304N, 304LN, 309, 310, 310S, 316, 316H, 316L, 316LN, 316Ti, 317, 317L, 321, 321H, 347, 347H, 348, 348H, 904L, XM10, XM11, XM15, XM19, XM29.

Duplex & Super Duplex Steel ERW Pipes & Tubes : ASTM A240 / ASME SA240 UNS NO S31803, S32205. Werkstoff No. 1.4462

Carbon Steel ERW Pipes & Tubes : ASTM A53, ASTM A106 Gr. A , B & C API 5L Gr. A / B, X42 ,X52 ,X60, ASTM A 53 Gr. A/B, ASTM A 333 GR.1/6 ASTM A179, ASTM A192 ASTM A179, DIN 17175/2391 BS 3059/ Gr 1 & Gr 2, ASTM A 334 GR.1/8/6

Alloy Steel ERW Pipes & Tubes : ASTM A530 / A530M ASTM A 335 GR.P- 1, ASTM A 335 GR.P- 5, ASTM A 335 GR.P- 9, ASTM A 335 GR.P-11, ASTM A 335 GR.P-22, ASTM A 335 GR.P-91. ASTM A 213 T1,T2,T5,T9,T11,T12,T22,T91 DIN 17175 CR.-MO Tubes

Nickel Alloy ERW Pipes & Tubes : ASTM B163, B161, B725, B730 / ASME B163, B161, B725, B730 UNS 2200 (Nickel 200), UNS 2201 (Nickel 201), UNS 4400 (Monel 400), UNS 8020 (Alloy 20 / 20 CB 3, UNS 8825 Inconel (825), UNS 6600 (Inconel 600), UNS 6601 ( Inconel 601), UNS 6625 (Inconel 625), UNS 10276 (Hastelloy C 276)
